XCMG 60 Ton Mobile Crane

Key Specification

• Overall Dimensions (L × W × H): 14,354 × 3,290 × 3,750 mm

• Wheelbase: 4,000 mm

• Track (Front / Rear): 2,520 / 2,520 mm

• Front / Rear Overhang: 2,200 / 2,400 mm

• Gross Vehicle Weight: 44,055 kg (6.3 t counterweight) / 46,755 kg (9 t counterweight)

• Axle Load (1st / 2nd): 25,298 / 18,757 kg or 24,252 / 22,503 kg

• Engine: SC9DK260.1G3 / QSB6.7-C260-30

• Engine Power: 192 kW @ 2000 rpm / 194 kW @ 2200 rpm

• Max Travel Speed: ≥ 40 km/h

• Min Travel Speed: 1.8 km/h

• Min Turning Diameter: ≤ 13 m

• Ground Clearance: 475 mm

• Approach / Departure Angle: 23° / 21°

• Braking Distance (at 24 km/h): ≤ 9 m

• Max Gradeability: ≥ 67%
